Model: D16PRO

Size: 194*175*88mm

Weight: 1.14kg

Max pressure: 20PSI

Battery capacity: 2600mAh  14.8V 38.48Wh

Working temperature: -10℃-60℃

Working current: max 10A

Type-C Input: IN 5V 3A,9V 3A,12V 2.5A,15V 2A,20V 1.5A

Type-C output: 5V 3A,9V 3A,12V 2.5A,15V 2A,20V 1.5A

Working Voltage: 14.8V

Usage: Inflation and deflation for inflatable SUP, Surfing Kite, Swing Ring, Boat, bed, tent, Mattress etc.

Working Mode:

-FAN: Inflate withe the fan (larger air flow, max aire pressure 1psi)

-CPR: Inflate withe the compressor (smaller air flow, max air pressure 20psi)

-AUT: Inflate with the fan when the current pressure is under 0.8psi, and inflate with the compressor over 0.8psi.

Protection Mechanism:

1. The air pump will automatically shut down after 1 minute if there is no operation and it's not inflating

2. The air pump will automatically stop when it is continuously inflated for 20 minutes to avoidcontinuous work caused by abnormal working conditions

3. The air pump will automatically stop when it is continuously inflated for 10 minutes and the airpressure is lower than 1 PSl, so as not to continue to work ineffectively.
